- Entry level: Detector for the introduction to 3D ground scan technology, combined with a VLF coil for finding treasures
- Detection depth: Customers found objects down to 8 m (26 ft) deep
- Use cases: Treasure hunting, cavity detection, natural gold prospection
- Operating modes: 3D Ground Scan, Live Sound
- Detectable objects: Treasure chests, cavities, tunnels
plus VAT, shipping and fees
Mon - Fri 10 am - 6 pm Sat - Sun by appointment only
Languages: Türkçe (TR), English (EN)
3D Visualization
3D Ground Scan
Color Display / Touchscreen
GST / EMSR
Height Adjustment
VLF Search Coil
LED Lighting
Multilingual Operation
Rechargeable High-Capacity Battery
Speaker
Wireless Technology
3D Metal Detector for Treasure Hunters and Gold Seekers
The metal detector and 3D ground scanner Evolution NTX can be used by treasure hunters, gold seekers, metal detectorists and archaeologists who are looking for buried objects, hidden artifacts or other lost items like:
- Lost valuables (rings, coins, jewelries, wedding bands)
- Buried treasures and artifacts
- Ancient boxes, chests, chambers and sepulchers
Unlike other metal detectors, the Evolution NTX can process graphical 3D images of underground treasure hoards and detected anomalies. Thus, you can determine size and depth of potential finds before digging. The deep penetration capability is just another advantage of our 3D ground scanner. Many great treasure finds prove the potential of our metal detecting technology made in Germany.
3D Metal Detector for Treasure Hunters and Gold Seekers
The successor of Evolution, Evolution NTX, is more compact and comes with improved features like rechargeable internal batteries, easier usability and more powerful sensor and coil technology.
Improved Usability
Based on our experiences as well as suggestions of many OKM users the new model has been improved and optimized in various aspects:
- Long-lasting and rechargeable batteries
- Color touchscreen with higher resolution
- Integration of Bluetooth headphones
- More compact and robust design
- Improved sensor and coil technology
Full color display with touchscreen and multilingual user interface allow an easier usability and setup of the metal detector Evolution NTX. The brightness of the screen can be adjusted individually.
VLF Metal Detector
The combination of our sensor technology with a VLF search coil allows detecting not only near-surface metals, but also deeply buried artifacts and treasure objects.
Evolution NTX with telescopic search coil: The length of the metal detector Evolution NTX can be adjusted to the individual body height of its user.
Ground Scan and Metal Detection
The 3D ground scanner Evolution NTX supports two operating modes to research the underground soils for hidden objects and structures. The length of the detector can be adjusted individually according to your own body height. Thus, you can make this metal detector your metal detector.
Starting at the main menu, you simply select one of the operating modes:
-
Live Sound
This operating mode activates the VLF metal detector to find shallow metal objects like coins, rings and other jewelry. Next to an acoustical output, you can also see a simple graphical indication of the signals. -
3D Scan
This operating mode is used to conduct graphical 3D ground scans. All scan data is stored into the device’s memory. This information can be transferred to the Visualizer 3D Software to generate graphical 3D images of underground objects and structures.
3D images via Visualizer 3D Software
The metal detector and 3D ground scanner Evolution NTX can be used by treasure hunters, gold seekers, metal detectorists and archaeologists.
With the 3D scan function and the software Visualizer 3D you can create a 3D graphic of the underground and find buried coins, rings, jewelry and similar treasure objects and artifacts. Especially metallic objects can be detected successfully. Buried objects are indicated by different colors in a graphical 3D representation.
Treasure Hunting
Archaeology
Militaria Detection
Cavity Detection
Explosive Ordnance Disposal Services
OKM Search Services
1x Control Unit |
1x Pre-configured Windows Notebook |
1x USB Flash Drive with OKM Visualizer 3D Studio Standard Edition |
1x Bluetooth Headphones incl. charging cable |
1x Charger with charging cable |
1x Travel Adapter Set |
1x Waterproof and shock-resistant Protector Case |
1x Quick Start Guide |
Control unit
- Dimensions (H x W x D): 540–810 x 150 x 280 mm
- Weight: approx. 1.5 kg
- Input voltage (max.): 19 V DC, 3.16 A, 60 W
- Processor / Main CPU: Cortex M3, 32 MHz
- Processor / Slave CPU: Cortex M0, 24 MHz
- Display: 3.5” Resistive touch, 480 x 320 Pixel
- Display CPU: Cortex M3, 32 MHz, 128 KB RAM
- Data memory: 4 GB
- Sample rate: 1024 values / second
- Measurement resolution: 16 bit
- Operating temperature: –10°C – 60°C
- Storage temperature: –20°C – 70°C
- Audio: Internal speaker / Bluetooth
- Waterproof: No
- Technology: GST / EMSR
- Sensor technology / Coil technology: SCMI-15-D / VLF
- Air humidity: 5% – 75%
Data Transmission
- Technology: Bluetooth 5.1
- Frequency: 2.402 – 2.480 GHz
- Maximum Transfer Rate: 1 Mbps
- Maximum Transmitting Power: +8 dBm
- Maximum Range: approx. 10 m
Computer Minimum Requirements
- Interface (data transmission): USB 2.0
- Free disk space: minimum 250 MB
- Working memory (RAM): 2 GB
- Display: 1920 x 1080
- Processor: 1.2 GHz
- Graphics card: 1 GB RAM, OpenGL 3.3
- Operating system: Windows 10
The technical data are average values. Minor deviations are possible during operation.
Evolution NTX
Product Flyer
Languages: English, Deutsch, Français, Español
Last updated: May 23, 2024
File size: 2.09 MB
Evolution NTX
Quick Start Guide
Languages: English, Deutsch
Last updated: November 03, 2020
File size: 1.6 MB
Evolution NTX (3.4 or higher)
Quick Start Guide
Languages: English, Deutsch
Last updated: July 29, 2021
File size: 863.11 kB
Evolution NTX (3.4 or higher)
Manual
Language: English
Last updated: June 11, 2021
File size: 2.13 MB
